RSB-2U8RDU
| 2U终端MIMO屏蔽盒， 含2子屏蔽空间
| 19”,2U, 350mm深 | 子空间: 100x200x15 | ＞60dB@0.7~8.5GHz | SMA-Female x16 USB3.0/5Gbps x2 |
| RSB-C601-081 | 2U抽屉式屏蔽盒， 含2子屏蔽空间 | 19”,2U, 360mm深 |
| ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x16 未预装任何EMI滤波器 |
| RSB-C601-080 | 3U抽屉式屏蔽盒， 含4子屏蔽空间 | 19”,3U, 360mm深 | 子空间： 80x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x16 未预装任何EMI滤波器 |
| RSB-C601-005 | 3U抽屉式屏蔽盒， 含4子屏蔽空间 | 19”,3U, 360mm深 | 子空间： 80x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x16 USB2.0 x8
RJ45/1Gbps x8
DC 7.5A x8 |
| RSB-C601-018 | 3U 抽屉式屏蔽盒， 含4子屏蔽空间 | 19”,3U, 360mm深 | 子空间： 80x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x16 USB3.0/5Gbps x8
RJ45/1Gbps x8
DC 7.5A x8 |
| RSB-C601-003 | 3U抽屉式屏蔽盒， 含6子屏蔽空间 | 19”,3U, 360mm深 | 子空间： 55x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x12 USB2.0 x6
RJ45/1Gbps x6
DC 7.5A x6 |
| RSB-C601-011 | 3U 抽屉式屏蔽盒， 含6子屏蔽空间 | 19”,3U, 360mm深 | 子空间： 55x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x12 USB3.0/5Gbps x6
RJ45/1Gbps x6
DC 7.5A x6 |
| RSB-C601-010 | 3U抽屉式屏蔽盒 | 19”,3U, 360mm深 | 340 x300x100 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x12 USB2.0 x12 |
| RSB-C601-047 | 4U抽屉式屏蔽盒， 含散热风扇 x 2 | 19”,4U, 360mm深 | 370 x300x150 | ＞65dB@0.7~2GHz ＞60dB@2~4GHz ＞55dB@4~6GHz | SMA-Female x16 USB2.0 x8
RJ45/1Gbps x8
DC 7.5A x8 |
| RSB-C601-084 | 屏蔽盒,6U,410mm深 含2子屏蔽空间 | 19”,6U, 410mm深 | 子空间： 140x360x200 | ＞70dB@0.7~6GHz | SMA-Female x16 USB3.0/5Gbps x4
AC 15A x8 |
| RSB-C601-078 | 屏蔽盒,6U,450mm深 | 19”,6U, 450mm深 | 340 x390x180 | ＞70dB@0.7~6GHz ＞65dB@6~8.5GHz | SMA-Female x8 N-Female x4 USB3.0/5Gbps x2
RJ45/1Gbps x2
DC 7.5A x2 AC 10A x1 |
| RSB-C601-032 | 屏蔽盒,8U,565mm深 | 19”,8U, 565mm深 | 340 x500x270 | ＞70dB@0.7~6GHz | SMA-Female x8 N-Female x8 USB3.0/5Gbps x3
RJ45/1Gbps x3
DC 7.5A x3 DC 40A x1 AC 10A x1 |
